FEATURES AND BENEFITS
10-Year Warranty
No Salt/Potassium to Buy
No Filter Changes Ever
No Maintenance for Warranty Period
Certified Safe for Septic Systems and Locations Where Water Softeners Are Banned
Removes Offensive Odors
Removes Up To 10 PPM Of Iron And Sulfur
Removes Offensive Odors
Removes Up To 5 PPM Of Manganese
Controls Bacteria and Algae
Diminishes Scale Build Up with Salt-Free Descaling Technology
The Best Option for Use With All Water Heaters, Even Tankless
Environmentally Friendly Option to Salt-Based Softeners
Conserves Water and Electricity Via Innovative Technology
Stainless Steel Bypass Valve and Hardware Kit
Made in the U.S.A.
What This Means for You
Better tasting, highly filtered alkaline water for drinking and cooking
(Ph may vary slightly depending on your geographical location)
No service calls, salt purchases or expensive filters to replace
Reduces deterioration of plumbing, pipes, sinks, tubs and appliances
Reduces energy and water waste
Harsh chemicals are eliminated
Saves money
Better drinking water for your pets
Healthier hair and skin
Improves air quality in your home
Whiter, brighter clothes
6 Stages of Water Filtration
Stage
KDF85
Removes or reduces iron and hydrogen sulfide from water. Controls scale, bacteria and algae. Redox media alloy functions as a catalyst to change soluble ferrous cat ions (positively charged ions) into insoluble ferric hydroxide, which can be easily removed with regular backwashing. Utilizing dissolved oxygen in the water, iron removal rates of 98% or better are common in laboratory studies.
Stage
Oxygen
Water flows through the upper cavity, making contact with injected oxygen (O2). This oxygenated water maximizes the removal efficiency of the multiple filtration stages.
Stage
GAC
Granular Activated Carbon is highly porous, natural substance that helps with removing iron and sulfur residuals as well as neutralizes bad odors and flavors.
Stage
Katalox
Katalox is a hybrid media shown to be one of the most effective methods of efficiently removing iron and sulfur from well water. This combination offers efficient contamination reduction and requires less regeneration water. This acts as a catalyst by accelerating the chemical reactions without being consumed or chemically changed by the reactions.
Stage
Garnet Mineral Stone
Water passes through a layer of natural garnet minerals removing suspended solids and sedimentation down to 10 microns. This allows for maximum water distribution and backwash efficacy.
Stage
Catalytic Converter
When water passes through the catalytic converter it goes through a turbulent interaction with a catalytic core made of a proprietary alloy. The unrelated metals combine with the water to create a battery effect that generates a tiny electrical charge. The charge effect generates a chemical reaction converting scale-forming calcium bicarbonate, to a non-scale forming calcium called aragonite. Healthy minerals are maintained, while the damaging consequences of hard water scale are eliminated.
New aragonite crystal formations are constantly produced to prevent the lime scale deposits created by hard water. The process also gradually removes any hard water deposits that have accumulated previously.
Vortech® Technology
Vortech® is the world's most innovative and efficient universal distribution system for water treatment systems, in filtration and softening applications. The design creates fluidity of the media bed and extends contaminant removal capacity up to 80%. This means less water waste and improved water quality.
Made in the USA
Each Modern Filtration System is hand-built right here in the United States to ensure the highest quality manufacturing and materials.
Specifications
| MODEL NUMBER | PRE-WEL-1054 | PRE-WEL-1354 |
|---|---|---|
| Tank Size | Up to 4 Bathrooms | Up to 6 Bathrooms |
| Filtration Stages | 6 Stages | 6 Stages |
| Media Types | KDF85 / GAC / Katalox / Garnet Mineral | KDF55 / Coconut Shell Carbon / Quartz |
| Descaler | Catalytic Converter | Quad Polarity Magnetic Ionizer |
| Filter Volume | 1.5 cubic feet | 2 cubic feet |
| Capacity (gallons) | Up to 1,000,000 | Up to 2,000,000 |
| Service Flow (GPM) | Up to 20 | Up to 20 |
| Tank Type | Vortech™ w/Mid-Plate | Vortech™ w/Mid-Plate |
| Tank Dimension | 10” x 54” | 13” x 54” |
| Weight (lbs) | 155 | 225 |
| Tank Construction | Blue Fiberglass | Blue Fiberglass |
| Valve Type | Digital w/ Blue LED display | Digital w/ Blue LED display |
| Backwash | Automatic | Automatic |
| Fitting Style | 1"FNPT | 1"FNPT |
| Max. Feed Pressure (psi) | 70 | 70 |
| Max. Feed Temp. (F) | 110 | 110 |
| Min. Feed Temp (F) | 33 | 33 |
| Warranty | 10 Years | 10 Years |
| Country of Manufacturer | USA | USA |
